Fuchs Titan UTTO TO-4 30

Super High Performance multifunctional transmission lubricant for construction machinery.

Fuchs Titan UTTO TO-4 SAE 30 is a Super High Performance multifunctional oil, which has been specially designed to meet the rigorous requirements of the CATERPILLAR TO-4 specification. This formulation is based on the latest components technology.

Application

TITAN UTTO TO-4 SAE 30 can be used in powershift transmissions, gearboxes, final drives and hydraulic systems, where the manufacturer dictates the use of CATERPILLAR TO-4 oil in the viscosity grade of SAE 30. Additionally TITAN UTTO TO-4 SAE 30 is recommended when oil in accordance to API GL-4, KOMATSU KES 07.868.1, ZF TE-ML 03C, ZF TE-ML 07F, ALLISON C-4, ALLISON TES-439 and many others more is specified. TITAN UTTO TO-4 SAE 30 is miscible and compatible with CAT TO-2 oils, also as with conventional hydraulic fluids and engine oils, which makes it easy to change over to TITAN UTTO TO-4 SAE 30.

TITAN UTTO TO-4 SAE 30 is miscible and compatible with conventionally branded UTTO´s, gear- and engine oils. However, mixing with other UTTO´s, gear and engine oils should be avoided in order to fully utilize the product’s benefits. Therefore, a complete oil change is recommended when converting to TITAN UTTO TO-4 SAE 30. For information on product safety and proper disposal please refer to the latest Material Safety Data Sheet.

Advantages/Benefits

• Excellent foam control protection
• top performance in wet brakes
• excellent control of brake chatter
• Extended friction-lining life of brakes and clutches
• Outstanding wear control for gears and hydraulic
• Improved thermal and oxidation stability
• Wide application range
• Additionally available in a large number of viscosity grades (SAE 10W / 30 / 40 / 50 / 60) for all operation conditions. Please choose the viscosity grade in accordance to manufacturer’s recommendations and the operational conditions.

Specifications

• API GL-4
• CAT TO-4

Approvals

• ZF TE-ML 03C, 07F (ZF002185)

FUCHS Recommendations

• ALLISON C-4
• ALLISON TES-439
• KOMATSU KES 07.868.1

PN: 600904319

Please contact for all Technical Data and Safety information documents
